SolvTrue™ PW Series Solvent Recyclers

For Parts Washing, Vapor Degreasing and Ultrasonic Parts Cleaning Applications

Recycle and Reuse Industrial Solvents with 99% Recovery

SolvTrue™ PW Series Solvent Recyclers enable you to improve operational throughput and can integrate with most parts washers or degreasers. Our PW Series recyclers afford an annual reduction of solvent purchase and disposal costs by upwards of 90% simply by enabling the reuse of clean solvent as recovered from the recycler and reducing overall waste volume.

PW Series recyclers can process solvents including methylene chloride, trans-1,2-dichloroethylene blends, trichloroethylene, Perchloroethylene, Vertrel™ series, Novec™ series, N-propyl bromide and other solvents used for parts cleaning and degreasing.

Achieve sustainability and cost savings in your facility with solvent recycling.



Benefits & Features:

  • Can integrate with most parts washers or degreasers
  • Consistently clean solvents and parts reduces breakdowns and extends the life of parts washer equipment
  • Save time with continuous recycling by transferring dirty solvent directly from the boiling sump of the degreaser and delivering clean, fresh solvent back into the immersion sump
  • Rejected parts and repeat runs are appreciably reduced by using clean solvents all the time
  • Batch and continuous-recycling models available
  • Waste transfer fill pumps are available to reduce spill risk
  • Automatic shutdown sensors and pressure-relief valves are included
  • Satisfy the latest Uniform Fire Code (UFC) requirements
  • UL2208 certified for use in non-hazardous environments



SolvTrue™ PW-1 Solvent Recycler

SolvTrue™ PW-1 Solvent Recycler

The SolvTrue™ PW-1 Recycler features gravity feed solvent recovery with manual waste drain valve and automatic fill pump. Available in 15- and 30-gallon capacities, the system is air cooled with stainless steel construction and 30” legs. Optional features are available, download spec sheet for full details.

Capacity:

15 gallon (57 liter)

30 gallon (114 liter)

Dimensions:

53" H x 48" W x 36" D (134 cm H x 122 cm W x 92 cm D)

Fill Device:

Automatic fill pump

Cooling:

Air cooled

Water cooled and chiller – Optional

Waste Drain:

Manual waste drain valve



  Download Spec Sheet

Electrical Configurations:

240V/3PH/60Hz – Standard

480V/3PH/60Hz – Optional

220V/1PH/60Hz – Optional

Solvent Recovery Type:

Gravity feed solvent recovery

Construction:

Stainless steel

Recycler Height:

30” legs – Standard

40” legs – Optional

SEND ME MORE INFO

or call 1-800-941-9484 to speak with a specialist.

Please fill out the form below to learn more about the SolvTrue™ PW-1 Solvent Recycler.




SolvTrue™ PW-2 Solvent Recycler

SolvTrue™ PW-2 Solvent Recycler

The SolvTrue™ PW-2 Recycler features pass-thru solvent recovery with manual waste drain valve and automatic fill pump. Available in 15- and 30-gallon capacities, the system is air cooled with stainless steel construction and 30” legs. Optional features are available, download spec sheet for full details.

Capacity:

15 gallon (57 liter)

30 gallon (114 liter)

Dimensions:

53" H x 48" W x 36" D (134 cm H x 122 cm W x 92 cm D)

Fill Device:

Automatic fill pump

Cooling:

Air cooled

Water cooled and chiller – Optional

Waste Drain:

Manual waste drain valve



  Download Spec Sheet

Electrical Configurations:

240V/3PH/60Hz – Standard

480V/3PH/60Hz – Optional

220V/1PH/60Hz – Optional

Solvent Recovery Type:

Pass-thru recovery

Construction:

Stainless steel

Recycler Height:

30” legs – Standard

40” legs – Optional

SEND ME MORE INFO

or call 1-800-941-9484 to speak with a specialist.

Please fill out the form below to learn more about the SolvTrue™ PW-2 Solvent Recycler.




SolvTrue™ PW-3 Solvent Recycler

SolvTrue™ PW-3 Solvent Recycler

The SolvTrue™ PW-3 Recycler features pass-thru solvent recovery with waste drain valve actuator and automatic fill pump. Available in 15- and 30-gallon capacities, the system is air cooled with stainless steel construction and 30” legs. Optional features are available, download spec sheet for full details.

Capacity:

15 gallon (57 liter)

30 gallon (114 liter)

Dimensions:

53" H x 48" W x 36" D (134 cm H x 122 cm W x 92 cm D)

Fill Device:

Automatic fill pump

Cooling:

Air cooled

Water cooled and chiller – Optional

Waste Drain:

Waste drain valve actuator



  Download Spec Sheet

Electrical Configurations:

240V/3PH/60Hz – Standard

480V/3PH/60Hz – Optional

220V/1PH/60Hz – Optional

Solvent Recovery Type:

Pass-thru recovery

Construction:

Stainless steel

Recycler Height:

30” legs – Standard

40” legs – Optional

SEND ME MORE INFO

or call 1-800-941-9484 to speak with a specialist.

Please fill out the form below to learn more about the SolvTrue™ PW-3 Solvent Recycler.




SolvTrue™ PW-4 Solvent Recycler

SolvTrue™ PW-4 Solvent Recycler

The SolvTrue™ PW-4 Recycler features pass-thru solvent recovery with waste drain valve actuator automatic pump and automatic fill pump. Available in 15- and 30-gallon capacities, the system is air cooled with stainless steel construction and 15” legs. Optional features are available, download spec sheet for full details.

Capacity:

15 gallon (57 liter)

30 gallon (114 liter)

Dimensions:

53" H x 48" W x 36" D (134 cm H x 122 cm W x 92 cm D)

Fill Device:

Automatic fill pump

Cooling:

Air cooled

Water cooled and chiller – Optional

Waste Drain:

Waste drain valve actuator with automatic pump



  Download Spec Sheet

Electrical Configurations:

240V/3PH/60Hz – Standard

480V/3PH/60Hz – Optional

220V/1PH/60Hz – Optional

Solvent Recovery Type:

Pass-thru recovery

Construction:

Stainless steel

Recycler Height:

15” legs – Standard

30” legs – Optional

40” legs – Optional

SEND ME MORE INFO

or call 1-800-941-9484 to speak with a specialist.

Please fill out the form below to learn more about the SolvTrue™ PW-4 Solvent Recycler.
